Invacare Rea Dahlia

From £1,464.00£2,462.00

  • VAT exempt
  • Crash tested
  • Free nationwide assessments, delivery and set-up
Clear

 Leader in modern tilt-in-space wheelchairs

The Invacare Rea Dahlia tilt-in-space wheelchair’s sleek and stylish appearance incorporates a narrow wheelbase and increased tilt options with easy adjustability, synonymous with the Invacare Rea range of passive wheelchairs.

The Invacare Rea Dahlia tilt-in-space wheelchair features two seat tilt angles of either 30° or 45°, improving the positioning capabilities to reduce pressure. Designed to manage all aspects of postural support and comfort, the versatile seating system offers a wide choice of options and adjustments to ensure the exact requirements of every individual are met.

The Invacare Rea Dahlia tilt-in-space wheelchair is the chair of choice, where increased seat tilt and compact manoeuvrability are key.

The Invacare Rea Dahlia tilt-in-space wheelchair is designed to accommodate various positioning requirements.  Attendant gas pistons easily adjust tilt and recline for light and effortless positioning.  An optional electric-controlled version offers independent control of posture and comfort.  Adjustments are abundant on the Rea Dahlia, with every aspect of the wheelchair and seating system adaptable for the perfect level of support and postural management.

Invacare-Logo

Narrow wheelbase and increased tilt options with easy adjustability

Rea Dahlia Invacare Tilt-in-Space Manual Wheelchair 1

Stability is a strong feature of the Rea Dahlia, delivering exceptional safety and confidence for the client with our unique DSS (Dual Stability System) built into every wheelchair.  When tilting and reclining, the seating system moves forward along the frame. This weight shifting guarantees exceptional stability, even when in full tilt and recline.  Additionally, the Rea Dahlia’s pivot points match the person’s natural pivot points for synchronised movement between the body and wheelchair, reducing the risk of sheer pressure.

Wide range of options

In addition to the multiple adjustments in the chair, the Invacare Rea Dahlia tilt-in-space wheelchair boasts many options and accessories, guaranteeing a solution for a wide range of postural challenges.

Seat tilt and Backrest recline

The Invacare Rea Dahlia tilt-in-space wheelchair features 30° or 45° of seat tilt and 30° of backrest recline supporting a range of positions. The unique construction of the tilt and recline mechanism delivers smooth and light action, which is ideal for smaller carers.

Outrigged Pivot Joint

Enables the pivot points of the backrest to be adjusted wider by 50mm overall, creating more seat space. A wider backrest is fitted, which is ideal for those requiring additional support.

Adjustable centre of gravity

The rear wheel position can be adjusted to increase the lightness and manoeuvrability of the Invacare Rea Dahlia tilt-in-space wheelchair. It also allows access to self-propel wheels for increased independence.  Transit wheels are available for attendant propulsion.

Comfortable propelling and compact frame

The rear wheels are closer to the user’s body, increasing comfort and enabling the Dahlia to be easily propelled.

Excellence in manoeuvrability

The Invacare Rea Dahlia tilt-in-space wheelchair can be easily propelled with minimum effort as the rear wheels can be moved forward and closer to the user’s arm.

Individualised seat height adjustment

Low seat-to-floor height gives the user the possibility to foot propel. Invacare Rea Dahlia tilt-in-space wheelchair brinks a large range of adjustments from 325 to 505 mm to meet user requirements.

Light tilt movement

The carer can tilt easily with minimum effort. The Invacare Rea Dahlia 45 tilt-in-space wheelchair includes a push-up spring, making it easier for the chair to come up from a tilted position.

The Invacare Rea Dahlia 45 tilt-in-space wheelchair allows a 45° tilt angle to deliver excellent pressure relief properties for patients who cannot use the recline to weight shift.

Need some help?

Contact us! Recare specialist consultants can arrange an initial call to help you find the optimal product for your personalised needs. As a trusted family-run business, we focus on your independence and quality of life.

See the Recare Wheelchair Guide to learn more.

Brand

Invacare

Invacare manufactures wheelchairs, powered seating products, electronics and accessories. A quality range of products that offer style and provide all the options to satisfy the most demanding users.
Invacare-Logo

Brochure

Download

Accessories Brochure

Download

Order Form - Rea Dahlia 45

Download

Order Form - Rea Dahlia 30

Download

Order Form - Rea Dahlia 45 Base

Download

User Manual

Download

Technical Specifications

Rea AzaleaRea Dahlia
SEAT WIDTH15 - 24" | 39 - 59 cm15 - 24" | 39 - 59 cm
SEAT DEPTH17 - 20" | 43 - 50 cm17 - 20" | 43 - 50 cm
SEAT ANGLE-1° - 23°30°: –1 - 30°
45°: 0 - 45°
SEAT HEIGHT16 - 18" | 40 - 45 cm13 - 20" | 33 - 50 cm
BACKREST ANGLE0° - 30°
0° - 30°
BACKREST HEIGHT21 - 31" | 54 - 79 cm20 - 31" | 50 - 80 cm
LENGTH OF FOOTRESTS13 - 20" | 33 - 50 cm13 - 20" | 33 - 50 cm
ARMREST HEIGHT9.5 - 14" | 24 - 36 cm12.5 - 14" | 25 - 32 cm
DRIVING UNIT WIDTH(Seat width) + 9" | 23 cm(Seat width) + 7" | 18 cm
TOTAL LENGTH37 - 40" | 95 - 102 cm35 - 47" | 90 - 118 cm
TOTAL HEIGHT35 - 49" | 90 - 125 cm32 - 49" | 82 - 125 cm
MAX. SAFE SLOPE
MAX. USER WEIGHT135 kg | 297 lbs135 kg | 297 lbs
TOTAL WEIGHT34 kg | 75 lbs34 kg | 75 lbs
TRANSPORT WEIGHT16.5 kg | 36.4 lbs25 kg | 55 lbs
FRAME COLOURPearl Grey
Azurite Blue
Sand
Happy Red
Electric Green
Black
COLOUR (OTHER)Multi stretch PU black fabric TR26
Black Plush TR35
Black Spacer TR36
Multi stretch PU black fabric TR26
Black Plush TR35
Black Spacer TR36

Seating Solutions

Struggling with Seating or Pressure Relief Issues? Recare Has the Solution

At Recare, we specialise in mobility, rehabilitation, and seating solutions to improve comfort, posture, and pressure management for wheelchair and powerchair users. Our expert in-house seating specialists work closely with you and your healthcare professional—whether an occupational therapist (OT) or physiotherapist—to ensure you receive the best seating support.

Choosing the Right Seating Solution for Your Needs

We offer three levels of seating assessments, from essential wheelchair seating prescriptions to advanced, custom-moulded solutions for complex postural and pressure relief needs.

Level 1: Standard Seating Evaluation (Free of charge: Included in your product assessment)

Our standard assessment ensures your wheelchair or powerchair has the right cushion and backrest for your needs. Whether in our clinic or at home, this service is part of your tailored wheelchair assessment to maximise comfort and mobility.

Level 2: Pressure Mapping Assessment (Assessment rate £450)

A Recare seating specialist will conduct a pressure mapping assessment to prevent pressure sores and discomfort. The assessment produces a live visual representation of the pressure areas in your seating, which is the most popular method for assessing the suitability of your current seating. To test alternative options to find a seating solution better suited for you based on comparing live visual data.

Level 3: Advanced Complex Seating Assessment (Free in the clinic)

We offer a comprehensive complex seating assessment for individuals requiring specialist seating solutions. In partnership with Ottobock specialists, we use 3D digital moulding technology to design a custom seating system that enhances stability, support, and pressure relief.

📍 In-clinic assessments are free of charge
🏠 At-home assessments are available. Please contact us for more information.

Why Choose Recare for Your Seating Needs?

Experienced seating specialists collaborating with healthcare professionals.
Tailored solutions for wheelchair and powerchair users to prevent pressure ulcers.
State-of-the-art pressure mapping and 3D seating technology.
✔ In-clinic and at-home assessments.

👉 Book your seating assessment today! Contact Recare to discuss your needs with our expert team.

Custom Order

This product is often made to measure and tailored to your specifications. Production and delivery for custom orders typically take 4 - 8 weeks, depending on the manufacturer's production process for all components of your order.

Please note that these timeframes are beyond the control of the Recare team at this point in your order.

Once your custom item is ready and your entire order is complete, the Recare team will contact you regarding your order.

Thank you for your patience. Our Recare team takes pride in creating high-quality, tailored solutions to meet your needs.
